Expert LD80 Battery Charger LiPO/NiMH 1-6S 80W - 230V

The Expert LD 80 Charger is a multi-function charger/discharger that allows you to use the most popular battery types such as LiPo/LiHV/Lilon/LiFe/NiCd/NiMH/Pb.
With a remarkable 80 watts of charging power and a maximum of 7A charging current, the Expert LD 80 charger offers more than sufficient charging power for most applications in a compact design.

With five separate balancer ports and the charging port on the right side the battery can easily be connected. There are also the AC and DC inputs on the left side.

Information about settings and running process can be obtained via the backlit LCD display.
The Expert LD 80 is the perfect multifunction charger and the right choice for most modeller.

Features:

• Compact design
• 80 watts charging power, max. 7A charging current
• Suitable for: LiPo/LiFe/LiIon/LiHV/NiMH/NiCd/Pb
• Easy handling and navigation with four buttons
• Informative LCD display with backlight
• Including 5 seperate Balancer ports
• 5 batteries profile memory
• Integrated balancer with max. 300mA current

Technical Specifications:

• Input Voltage AC:    100V - 240V
• Max Charge Power:    80W
• Max Discharge Power:    2W
• Charge Current Range:    0.1A - 7.0A
• Discharge Current Range:    0.1A - 1.0A
• Balancer current:    300mAh
• Cells: LiPo/LiFe/LiIon/LiHV    1s - 6S
• Cells: NiMH/NiCd    1s - 15S
• Pb Battery Voltage:    2-20V
• Weight:    400g
• Size:    136x127x56mm

Scope of  Delivery:

• 1x Expert LD 80 charger
• 1x Manual
• 1x Alligator Clips to DC Cable
• 1x Alligator Clips to Dean style connector
• 1x Mini JST (red) connector to Dean style connector cable
• 1x Female servo connector to Dean style connector cable
• 1x Glow plug connector to Dean style connector cable
• 1x 4mm banana connectors to Dean style connector cable
• 1x Power Cable
